Gas products

Omniguard® Model 1100

The Omniguard model 1100 gas detector is designed to detect and measure the presence and level of flammable gases. The detector is based on well proven sensor cell technologies and has excellent measuring accuracy and long term stability. The microprocessor controlled functionality and simple calibration procedure makes the Omniguard 1100 gas detector reliable in field operation. Easy to read display and standard 4-20mA and HART Rev 7 output makes installation and operation of the detector quick and easy.


D
OWNLOAD
DATA SHEET



Omniguard® model 2100

The Omniguard model 2100 gas detector is designed to detect and measure the presence and level of oxygen and toxic gases. The Omniguard model 2100 gas detector is based on well proven sensor cell technologies and has fast response rime, excellent measuring accuracy and long term stability. The microprocessor controlled functionality and simple calibration procedure makes the Omniguard 2100 gas detector reliable in field operation. Easy to read display and standard 4-20mA and HEART Rev 7 output makes installation and operation of the detector quick and easy.


DOWNLOAD
DATA SHEET


Omniguard® Model 3100

The Omniguard model 3100 infrared gas detector is designed to detect and measure the presence and level of a wide range of different gases. The detector is based on well proven sensor technology and has excellent measuring accuracy and long term stability as well as fast response time. The microprocessor controlled functionality and simple calibration procedure makes the Omniguard 3100 gas detector easy to use and maintain and also very reliable in field operation. Easy to read display and standard 4-20mA and HEART Rev 7 output makes installation and operation of the detector quick and easy.


DOWNLOAD
DATA SHEET


ACCESSORIES FOR GAS DETECTORS


Pole mount 2" for all 1100/2100 Gas detectors
Material: Stainless Steel 316L

Part number: 28236




Pole mount 2" for all 3100 Gas detectors
Material: Stainless Steel 316L

Part number: 28237




Weather shield for all 1100/2100/3100 Gas detectors
Material: Plastic
Part number: 27727


DOWNLOAD
DATA SHEET


Weather shield for all 1100/2100 Gas detectors
Material: Stainless Steel 304
Part Number: 28368


DOWNLOAD
DATA SHEET


Weather shield for all 3100 Gas detectors
Material: Stainless Steel 304
Part Number: 28346


DOWNLOAD
DATA SHEET


Magnet bar for all 1100/1200/3100 Gas detectors
Part number: 27730




Splash guard/Calibration cap for all 1100/2100 Gas detectors
Material: Plastic
Part number: 27728




Collecting Cone for all 1100/2100 Gas detectors
Material: Plastic
Part number: 27729



  • Certifications and approvals

    Omniguard's Gas detectors are available with the following certifications and approvals:





    OMNIGUARD® MODEL 1100

    Safety Integrity Level (SIL)
    Certificate: SGS TÜV SAAR FS/71/220/20/0568

    EX (II 2G Ex db IIC Gb)
    Certificate: Sira 19ATEX1134U
    Certificate: Sira 19ATEX1133U
    Certificate: Sira 19ATEX1078

    Classified for use in hazardous locations
    Class I, Division 1, Groups A, B, C and D hazardous locations.
    Certificate: UL control no. 5MH9


    OMNIGUARD® MODEL 2100

    Safety Integrity Level (SIL)
    Certificate: SGS TÜV SAAR FS/71/220/20/0567

    EX (II 2G Ex db IIC Gb)
    Certificate: Sira 19ATEX1134U
    Certificate: Sira 19ATEX1078

    Classified for use in hazardous locations
    Class I, Division 1, Groups A, B, C and D hazardous locations.
    Certificate: UL control no. 5MH9

    OMNIGUARD® MODEL 3100

    Safety Integrity Level (SIL)

    Certificate: SGS TÜV SAAR FS/71/220/20/0566

    EX (II 2G Ex db IIC Gb)
    Certificate: Sira 19ATEX1134U
    Certificate: Sira 19ATEX1133U
    Certificate: Sira 19ATEX1078

    Classified for use in hazardous locations
    Class I, Division 1, Groups A, B, C and D hazardous locations.
    Certificate: UL control no. 5MH9
